Carbon high performance cruising cat

This design was commissioned by a high performance dinghy sailor who was looking for a comparitive high performance cruising yacht that could be sailed short handed or raced competitively with a crew.

Cation has a better sail area/displacement ratio than her 20m sister Kotuku and is built in a similar fashion but with a more optimised structure as a result of a careful FEA analysis by PURE Engineering.

As an added quality assurance the structural design submitted to DnV/GL plan approval and passed.

This design features similar assymetric, high lift centreboards and rudder foils which combined produce an ability to sail to windward with equivalent height to a TP52, with no leeway.

Like the larger Kotuku this cat is fully fitted out for live aboard cruising, laundry, genset, air con., water maker, etc.

Download the Boating New Zealand review

Please checkout the video below:


Principal Particulars
LWL 18.4 m
LOA 18.5 m
Displacement 14350 kg
Draft 3.9 m
Beam 9 m
Upwind Sail Area 206.8
Drive Type Inboard
Survey Class 3
Construction 4
Builder Jon Douglas
Design Status Published
Design Number 161
Hull Form Catamaran
Design Type Custom


  • image
  • image
  • image
  • image
  • image
